Cabinet with door
Recessed into sides (hidden)
Adds a hinged door panel
Covers cabinet front
Distance from the Ø35mm hinge cup hole, to door edge
5 mm shelf-pin & hinge holes · 32 mm pitch · 37 mm from edges
Technical drawing
Design custom cabinets, download technical drawings.
Pick a cabinet type, configure it in 3D, and export a workshop-ready PDF or DXF for CNC cutting. New types are added regularly.
Available cabinets
View all →
Base Cabinet with Door
Classic rectangular carcass with one or two hinged doors. Overlay or inset, left or right swing, adjustable shelves.
Cabinet Door Custom
Standalone hinged door panel with Blum-style cup and pilot drilling. Export PDF and CNC-ready DXF.
Cabinet Door for Ikea PAX
Pre-sized door for Ikea PAX frames (500×1950 or 500×2290 mm). Pick a size and hinge direction — drilling pattern and dimensions are fixed.
Cabinet Door for Ikea METOD
Pre-sized door for Ikea METOD frames. Pick a standard size and hinge direction — drilling pattern and dimensions are fixed.
Base Cabinet with Drawers
Coming soonStack of full-extension drawers in a single carcass. Configurable drawer count and front heights.
Base Cabinet Angled Width
Coming soonCabinet with an angled top — fits under stairs or sloped ceilings. Set the left and right side heights independently.
Base Cabinet with Corner Obstruction
Carcass notched to clear a corner pipe, column, or wall return. Configurable obstruction size and position.
